SWAT®

QUALITY COUNTS!
PREMIUM SOLUTIONS FOR 12' - 22' (10 TO 40 CUBIC YARDS) ROLL-OFF CONTAINERS

The SWAT® was designed with the end user in mind. We’ve taken the technology and components of existing systems and built a better product! Engineered to provide you with the highest quality tarping system, keeping you up and running, all at a competitive price.

The SWAT® is a fully adjustable automatic tarping system for all 10 to 40 cubic yard containers. Made with precision-cut pivot gears and rack to help eliminate slippage, increase longevity and decrease cost. Its hard pipe cylinders with nitride-coated rams help reduce hose damage, and the flanged gear pin design ensures pins stay in place. The extreme-duty tarp roller features three mounting options: spline, square nut and threaded slot – and extended-life bearings. The wider tower mounting plate fits most plate hoist configurations and helps cut installation time. The SWAT® is powder coated for a premium finish and protection, and the low-profile arms help avoid damage from wide containers and compactors.

The SWAT® is topped with our Mighty Mesh® tarp, the strongest tarp material available. Mighty Mesh® tarps come equipped with a standard tarp spline, making tarp replacement a quick, easy, one-man job.

• Gear and Rack - Precision cut and built gear and rack.
• Hard-Pipe Cylinder - The hard-pipe cylinders with nitride coated rods reduce chances of hose damage.
• Tarp Tube - One person quick release tarp tube, with standard tube spline for easy tarp replacement.
• Spring Roller Bar - Industry leading extreme use spring roller bar.
• Mighty Mesh® Tarp - The strongest truck tarp material available on the market today.
• LiteALL™ Work Light - Includes mounting brackets and wiring protection tube are pre-installed.

BENEFITS
• SWAT® Parts Directly Replace Most Competitor Parts.
• Secure Flanged/Bolted Pivot Gear Pins Prevent Loosening to Gear Over time.
• 3/16" A500B steel arms, gussets and brackets engineered with exceptional durability to withstand demands of the industry.
• Low-profile arms avoid damage from wide containers and compactors.
• Covers a wider range of truck container sizes than competitor systems.
• SWAT® (Straight Arm) Covers 12'–16' OR 14'–18' Containers (Pivot Location Determines).
• SWAT® (Bent Arm) Covers 18'–21' Containers.
• SWAT® (Bent Arm) Covers 20'–22' Containers.
• Self-Contained Remote Control Operation.
• Includes Self-Contained Remote.

CABLE HOIST KITS
CONTAINER LENGTH	MIGHT MESH® TARP	ARM SYLE	w/o WET KIT	WET KIT	SELF CONT. w/REMOTE
12'-18'	8' x 28'	Straight Arm	1811710	1811712	1811714
12'-18'	9'8" x 28'	Straight Arm	1811711	1811713	1811715
18'-21'	8' x 28'	Bent Arm	1810407	1810409	1810411
18'-21'	9'8" x 28'	Bent Arm	1810408	1810410	1810412
20'-22'	8' x 28'	Bent Arm	1809616	1809618	1809621
20'-22'	9'8" x 28'	Bent Arm	1809617	1809619	1809622

HOOK LIFT KITS
CONTAINER LENGTH	MIGHT MESH® TARP	ARM SYLE	w/o WET KIT	WET KIT	SELF CONT. w/REMOTE	WET KIT HIGH PRESSURE
12'-18'	8' x 28'	Straight Arm	1811716	1811718	1811720	1811726
12'-18'	9'8" x 28'	Straight Arm	1811717	1811719	1811721	1811727
18'-21'	8' x 28'	Bent Arm	1810413	1810415	1810417	1810423
18'-21'	9'8" x 28'	Bent Arm	1810414	1810416	1810418	1810424
20'-22'	8' x 28'	Bent Arm	1809678	1809680	1809682	1809772
20'-22'	9'8" x 28'	Bent Arm	1809679	1809681	1809683	1809773

Call 1-800-327-8287 for Product Pricing.

Mighty Mesh® Tarps
• Mighty Mesh® Fits All Tarps
- 1801686 - 8' x 28'
- 1809674 - 8' x 28' w/Hook Lift Cutout
• Mighty Mesh® Tarp w/Flaps
- 1809640 - 9'8" x 28'
- 1809675 - 9'8" x 28 w/Hook Lift Cutout
• Mighty Mesh® Features
- Replacement tarp fits all brands of hydraulic roll-off tarper
- Tapered pocket end for ease of installation and enhanced appearance
- For flap tarps - side flaps on tarp extend lateral coverage
- For flap tarps - pre-installed bungee cord retracts flaps for smooth roll up
